自助取号机SW（ID:1408585）

机械设备 / 非标机械 / 自助取号机SW

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	17165167724891.zip	6.45M
2	Y01.3202.01-01REV01_右立柱.SLDPRT	71.81K
3	Y01.3202.01-02REV01_中连接件.SLDPRT	28.62K
4	Y01.3202.01-03REV01_顶封板.SLDPRT	40.00K
5	Y01.3202.01-04REV01_底封板.SLDPRT	37.74K
6	Y01.3202.01-05REV01_圆弧连接片.SLDPRT	20.08K
7	Y01.3202.01-06REV01_前连接件1.SLDPRT	25.90K
8	Y01.3202.01-07REV01_前加强板.SLDPRT	17.58K
9	Y01.3202.01-08REV01_U型固定槽.SLDPRT	27.00K
10	Y01.3202.01-09REV01_显示器卡板1.SLDPRT	23.32K
11	Y01.3202.01-10REV01_显示器卡板2.SLDPRT	23.11K
12	Y01.3202.01REV01_前箱体-焊接组.SLDASM	41.79K
13	Y01.3202.02-01REV01_侧板1.SLDPRT	86.29K
14	Y01.3202.02-02REV01_后侧板.SLDPRT	51.59K
15	Y01.3202.02-03REV01_圆弧片.SLDPRT	20.01K
16	Y01.3202.02-04REV01_连接件1.SLDPRT	36.32K
17	Y01.3202.02-05REV01_连接件2.SLDPRT	28.78K
18	Y01.3202.02-06REV01_U型固定件.SLDPRT	28.04K
19	Y01.3202.02REV01_后箱体-焊接组.SLDASM	39.10K
20	Y01.3202.03-1REV01_底座面板.SLDPRT	33.56K
21	Y01.3202.03-2REV01_底部边缘焊接件1.SLDPRT	26.07K
22	Y01.3202.03-3REV01_底部加强筋1.SLDPRT	25.13K
23	Y01.3202.03-4REV01_底部加强筋2.SLDPRT	29.04K
24	Y01.3202.03-5REV01_底部加强板1.SLDPRT	64.55K
25	Y01.3202.03-6REV01_底部加强板2.SLDPRT	26.34K
26	Y01.3202.03REV01_底座-焊接组.SLDASM	38.78K
27	Y01.3202.04-1REV01_上门板1.SLDPRT	257.15K
28	Y01.3202.04-2REV01_上门板2.SLDPRT	158.72K
29	Y01.3202.04REV01_上门板-焊接组.SLDASM	35.64K
30	Y01.3202.05-1REV01_中门板主体.SLDPRT	38.86K
31	Y01.3202.05REV01_中门板-焊接组.SLDASM	35.12K
32	Y01.3202.06-1REV01_下左门板1.SLDPRT	370.77K
33	Y01.3202.06-2REV01_下门板加强筋.SLDPRT	24.71K
34	Y01.3202.06REV01_下左门板-焊接组.SLDASM	35.49K
35	Y01.3202.07REV01_下右门板-焊接组.SLDASM	35.23K
36	Y01.3202.08-01REV01_面板主体.SLDPRT	91.21K
37	Y01.3202.08-02REV01_面板前框.SLDPRT	38.48K
38	Y01.3202.08-03REV01_面板圆弧片.SLDPRT	20.61K
39	Y01.3202.08-04REV01_面板侧封板.SLDPRT	19.88K
40	Y01.3202.08-05REV01_打印机纸固定架.SLDPRT	29.95K
41	Y01.3202.08REV01_前面板-焊接组.SLDASM	38.08K
42	Y01.3202.09-01REV01_支撑主体.SLDPRT	38.65K
43	Y01.3202.09-02REV01_支撑板侧板.SLDPRT	28.68K
44	Y01.3202.09-03REV01_Z型支撑件.SLDPRT	31.27K
45	Y01.3202.09-04REV01_支撑架固定焊接钣.SLDPRT	21.38K
46	Y01.3202.09REV01_支撑架-焊接组.SLDASM	37.26K
47	Y01.3202.10REV01_感应安装板.SLDPRT	39.37K
48	Y01.3202.13REV01_打印机安装板1.SLDPRT	37.94K
49	Y01.3202.14REV01_打印机安装板2.SLDPRT	56.63K
50	Y01.3202.15REV01_显示器压条1.SLDPRT	32.80K
51	Y01.3202.16REV01_显示器压条2.SLDPRT	31.23K
52	Y01.3202.17REV01_条码安装板1.SLDPRT	19.72K
53	Y01.3202.18REV01_条码安装板2.SLDPRT	20.53K
54	Y01.3202.19REV01_社保卡-焊接组.SLDPRT	22.55K
55	Y01.3202.20REV01_读卡器安装件.SLDPRT	65.21K
56	Y01.3202.22REV01_打印机适配器固定件.SLDPRT	28.89K
57	社保卡固定件.SLDPRT	37.63K
58	自助取号机-总装配.SLDASM	1.90M
59	自助取号机-总装配.STEP	10.94M
60	镜向Y01.3002.03-3REV01_底部加强筋1.SLDPRT	25.18K
61	镜向Y01.3202.01-01REV01_右立柱.SLDPRT	72.32K
62	镜向Y01.3202.02-01REV01_侧板1.SLDPRT	86.31K
63	镜向Y01.3202.09-02REV01_支撑板侧板.SLDPRT	29.42K
