树莓派1（ID:141512）

人与自然 / 植物 / 树莓派1

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	1939K460_DC EQUIPMENT COOLING FAN_step.prt	319.00K
2	2.54 mm DUPONT MALE PIN HEADER, IO, 2X20, RPi4ModelB.prt	720.00K
3	2.54 mm DUPONT MALE PIN HEADER, POE, 2X2, RPi4ModelB.prt	142.50K
4	2X USB2.0 PORTS, RPi4ModelB.prt	1.13M
5	2X USB2.0 PORTS, RPi4ModelB1.prt	103.50K
6	2X USB3.0 PORTS, RPi4ModelB.prt	1016.00K
7	91D77 D9WHV 778K, 4 GB LPDDR4 SDRAM, RPi4ModelB.prt	290.00K
8	base stack2_model2.prt	400.50K
9	base stack_model1.prt	464.50K
10	base stack_model2.prt	430.50K
11	Broadcom BCM2711B0 CPU, RPi4ModelB.prt	88.00K
12	Broadcom BCM54213PE Gigabit Ethernet Transceiver, RPi4ModelB.prt	728.00K
13	Camera Connector, RPi4ModelB.prt	944.00K
14	Cypress CYW43455 Wireless Module Cover, RPi4ModelB.prt	112.00K
15	Display Connector, RPi4ModelB.prt	944.00K
16	Female Micro HDMI Connector, RPi4ModelB.prt	936.00K
17	Female USB Type C Connector, RPi4ModelB.prt	376.50K
18	Gigabit Ethernet Port, RPi4ModelB.prt	382.00K
19	Microphone Plug, RPi4ModelB.prt	352.00K
20	MxL7704 Universal PMIC, RPi4ModelB.prt	333.00K
21	PCB, RPi4ModelB.prt	190.00K
22	pin_model1.prt	156.50K
23	profile 2_model1.prt	193.50K
24	profile_model1.prt	173.00K
25	Raspberry Pi 4 Model B_step.prt	83.00K
26	SD Card Slot, RPi4ModelB.prt	498.00K
27	stack case_asm1.prt	323.00K
28	stack.PNG	148.58K
29	VIA VL805 PCIe USB 3.0 controller, RPi4ModelB.prt	444.50K
