X1119-单速变速箱设计三维Step无参==709751=0（ID:1532903）

交通运输 / 车辆相关 / X1119-单速变速箱设计三维Step无参==709751=0

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	17244729334835.zip	9.60M
2	zongzhuangtu.step	18.11M
3	一般视角.png	118.13K
4	侧视图.png	83.38K
5	前视图.png	48.66K
6	渲染.png	655.60K
7	结构.png	80.82K
8	0_500_Hex_ID_x_1_125_OD_x_0_313_WD_Flanged_Bearing_v2_217-3875.prt	93.00K
9	12t_Aluminum_Spur_Gear_20_DP_CIM_Motor_217-2614.prt	153.00K
10	1_16_Acetal_Spacer_-_1_2_Hex_217-3257.prt	74.00K
11	1_2_Hex_Bore_Plastic_VersaHub_217-4009.prt	628.00K
12	1_8_Acetal_Spacer_-_1_2_Hex_217-2758.prt	73.50K
13	217-2588-001Rev4.prt	1.02M
14	217-2859-001Rev4.prt	1.09M
15	217-2859-011rev3.prt	608.00K
16	4_Traction_Tire_-_0_5_Wide_217-2859.prt	65.50K
17	4_Traction_Tire_-_0_5_Wide_217-2859_1.prt	65.50K
18	4_Traction_Wheel_-_1_Wide_217-2588.prt	78.50K
19	50t_Aluminum_Spur_Gear_20_DP_1_2_Hex_Bore_217-3572.prt	345.00K
20	56t_Aluminum_Spur_Gear_20_DP_1_2_Hex_Bore_217-5474.prt	355.00K
21	60t_Aluminum_Spur_Gear_20_DP_1_2_Hex_Bore_217-3574.prt	490.00K
22	90128A940_ZNC-PLTDALLOYSTLSCKTHEADCAPSCREW.prt	217.00K
23	91251A352_BLACK-OXIDEALLOYSTEELSOCKETHEADSCREW.prt	317.50K
24	91255A242_ALLOYSTEELBUTTON-HEADSOCKETCAPSCREW.prt	203.50K
25	92220A178_ALLOYSTEELLOW-PROFILESOCKETHEADSCREW.prt	320.00K
26	94559A511_ALUMULTRA-WIDEFLANGEDBUTTONHEADSCREWS.prt	180.00K
27	98408A138_SIDE-MOUNTEXTERNALRETAININGRINGE-STYLE.prt	82.50K
28	BEAM-0750.prt	85.00K
29	FIRSTSTAGESHAFT.prt	83.00K
30	mocktube.prt	81.00K
31	motorspacer.prt	72.00K
32	NUT-832-NYLOCK.prt	103.50K
