713小组-SDSMK2模块，针对通孔编码器进行了改进（ID:160432）

电力仪表 / 电气元件 / 713小组-SDSMK2模块，针对通孔编码器进行了改进

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	0.5 Hex Bearing (Vex 217-3875).SLDPRT	107.10K
2	91253A022_ALLOY STEEL FLAT-HEAD SOCKET CAP SCREW.SLDPRT	1.62M
3	92510A673_ALUM UNTHRD SPACER.SLDPRT	152.27K
4	93738A190_BARBED INSERTS FOR PLASTIC.SLDPRT	602.12K
5	98410A122_EXTERNAL RETAINING RING.SLDPRT	114.92K
6	Bearing, .375 ThunderHex, Flanged, 217-5829.sldprt	16.81K
7	Bearing, 688.sldprt	17.61K
8	Bearing, A035XPO_SA035XPO.sldprt	62.98K
9	Bearing, am-0573, 217-2732.sldprt	16.56K
10	Bearing, F689-ZZ.sldprt	14.77K
11	Bearing, FR8, am-0030, 217-3875.sldprt	56.51K
12	Bearing, R188ZZ, 217-3489.sldprt	15.38K
13	Belt, 320-5M-09.sldprt	17.33K
14	Drive Motor With Spacer.SLDASM	1.18M
15	Encoder, US Digital MA3-X-250-N, Nut.sldprt	63.08K
16	Gear, 20DP, 14T, 8mm Key Bore, Steel, 217-3414.sldprt	75.70K
17	Gear, 20DP, 18T, .375Hex, 217-3208.sldprt	100.64K
18	Gear, 20DP, 26T, .375Hex, 217-5453.sldprt	146.42K
19	Gear, 20DP, 42T, .375Hex, 217-3215.sldprt	146.15K
20	Gear, 32DP, 45T, .375Hex, am-3694.sldprt	84.82K
21	Gear, 32DP, 47T, Encoder Drive(Default).sldprt	110.43K
22	Gear, 32DP, 8mm, am-3482.sldprt	36.44K
23	Gear, Bevel, KSB1.5-1560, .375Hex, Shortened.sldprt	408.30K
24	Gear, Bevel, KSB1.5-6015, VersaHub(Default).sldprt	3.26M
25	MK2 Center Shaft V2.sldprt	30.94K
26	MK2 Encoder.JPG	61.72K
27	MK2 Intermediate Shaft.sldprt	24.80K
28	MK2 Main Plate no counterbore(With Chamfers).sldprt	177.72K
29	MK2 Main Plate with Encoder Modification.SLDPRT	851.46K
30	MK2 Main Pulley.sldprt	179.05K
31	MK2 Steering Shaft Assembly.SLDASM	104.05K
32	MK2 Steering Shaft V3, Pulley Flange.sldprt	26.26K
33	MK2 Steering Shaft V3.sldprt	56.32K
34	MK2.JPG	66.78K
35	Modified Gear, 32DP, 47T, Encoder(Default).sldprt	419.19K
36	Motor Shaft Spacer.SLDPRT	148.91K
37	Motor Spacer Drive.SLDPRT	247.87K
38	Motor Spacer.SLDPRT	249.28K
39	重复_Motor with spacer.SLDASM	1.16M
40	NEO (REV-21-1650).SLDPRT	615.27K
41	Retaining Ring, 8mm, 98430A132.sldprt	60.59K
42	REV-11-1271.SLDASM	4.92M
43	REV-11-1271.STEP	9.55M
44	REV-21-1650(1).STEP	937.09K
45	Screw, #12-14 X 1.5, Flat, Thread Forming.sldprt	81.99K
46	Screw, .25-20 X .75, Socket, 91251A540.sldprt	39.17K
47	Screw, .25-20 X 1 Socket, 91251A542.sldprt	42.79K
48	Screw, 10-32 X .25, Button, 91255A261.sldprt	33.69K
49	Screw, 10-32 X .375, 91251A340.sldprt	35.75K
50	Screw, 10-32 X 2.5, 91251A355.sldprt	53.73K
51	Screw, 12-24 X .625, Flat, 91253A282.sldprt	42.20K
52	Screw, 4-40 X .375, Flat, Torx, 92703A209.sldprt	60.83K
53	Screw, Shoulder, .375 X 2.5, 5_16-18, 91259A634.sldprt	124.89K
54	SDS MK2 Swerve Module.SLDASM	22.37M
55	SDS MK2 Swerve Module.STEP	44.23M
56	Shim, 8mm ID X 14mm OD X .5mm Thick, 98055A115.sldprt	15.58K
57	Spacer, #10 X 1.875, .3125 OD, 92510A554.sldprt	25.17K
58	Wheel Mount A(Default).sldprt	40.31K
59	Wheel Mount B(Default).sldprt	41.04K
60	Wheel Spacer.sldprt	25.25K
61	Wheel, Versa, 4in, DT, 217-3197, Modified.sldprt	1.54M
