发电厂轴流动叶可调式送风机三维模型--791443-450（ID:2149602）

机械设备 / 通用设备 / 发电厂轴流动叶可调式送风机三维模型--791443-450

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	17478214705553.zip	18.43M
2	air-blower-bear-box-body.prt.1	897.29K
3	air-blower-bear-end.prt.1	367.57K
4	air-blower-diffuser.prt.1	1.07M
5	air-blower-inlet-box.prt.1	1.24M
6	air-blower-main-axis.prt.1	854.37K
7	air-blower-main.asm.1	227.27K
8	air-blower-rotate-box-cover.prt.1	1.67M
9	air-blower-rotate-box-down.prt.1	1.88M
10	air-blower-rotate-box-up.prt.1	1.50M
11	air-blower-stationary-shroud-d.prt.1	2.57M
12	air-blower-stationary-shroud-up.prt.1	2.88M
13	ball-12-4.xas	133.13K
14	ball-18-9-2.xpr	48.99K
15	ball-2_5-1_25.xas	132.21K
16	ball-5-2_5-0_5.xpr	49.27K
17	ball-body-18-4.xpr	83.83K
18	ball-body-5-1_25.xpr	82.42K
19	ball-shell-2_5-1_25.xpr	81.60K
20	ball-shell-9-4.xpr	82.21K
21	body-8-6.xpr	87.37K
22	cylindrical-rolling-bear-body.prt.1	113.75K
23	cylindrical-rolling-bear-roll.prt.1	53.45K
24	cylindrical-rolling-bear-shell.prt.1	116.71K
25	cylindrical-rolling-bearing.asm.1	55.03K
26	deep-groove-ball-bearing-ball.prt.1	82.85K
27	deep-groove-ball-bearing-body.prt.1	144.49K
28	deep-groove-ball-bearing-shell.prt.1	139.83K
29	deep-groove-ball-bearing.asm.1	94.84K
30	main-bear-box-drive-cover.prt.1	381.39K
31	main-bear-box-drive-end.prt.1	837.28K
32	main-bear-box.asm.1	708.47K
33	main-movable-leaf.asm.1	447.27K
34	movable-leaf-adjust-divider.prt.1	82.22K
35	movable-leaf-adjust-guide-axis.prt.1	462.20K
36	movable-leaf-adjust-guide-end.prt.1	211.38K
37	movable-leaf-adjust-guide.prt.1	282.55K
38	movable-leaf-axis-bear-end.prt.1	503.56K
39	movable-leaf-axis-crank.prt.1	237.41K
40	movable-leaf-axis-leaf.prt.1	491.86K
41	movable-leaf-axis-sleeve.prt.1	603.67K
42	movable-leaf-axis-slider.prt.1	62.92K
43	movable-leaf-bracket-end.prt.1	480.88K
44	movable-leaf-bracket.prt.1	385.38K
45	movable-leaf-hub-adjust-body.prt.1	500.60K
46	movable-leaf-hub-adjust-end.prt.1	166.52K
47	movable-leaf-hub-cover.prt.1	427.60K
48	movable-leaf-hydraulic-body.prt.1	404.10K
49	movable-leaf-main-hub.prt.1	2.09M
50	normal-six-angle-screw.prt.1	725.29K
51	roll-18-8-6.xas	101.73K
52	roll-18-8-6.xpr	38.76K
53	screw-0_5-3-2-1.xpr	449.01K
54	shell-18-6.xpr	90.92K
55	source.idx	6.34K
