雕刻机总体(STEP)（ID:2335975）

机械设备 / 机加工设备 / 雕刻机总体(STEP)

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	17511755709518.rar	10.50M
2	装配体雕刻机总体.sldasm	5.10M
3	装配体雕刻机总体.sldprt-dtk.xml	200.68K
4	装配体雕刻机总体.stp	6.63M
5	CountersunkFlatHeadCrossRecessScrew_ISOISO7046-1-M3x30-Z---30N.sldprt	46.88K
6	ER11座.sldprt	110.69K
7	HexagonnutsgradeCGBGB_FASTENER_NUT_SNC1M5-N.sldprt	36.55K
8	HexagonnutsgradeCGBGB_FASTENER_NUT_SNC1M6-N.sldprt	36.21K
9	HexagonsocketheadcapscrewsGB1GB_FASTENER_SCREWS_HSHCSM5X10-N.sldprt	35.75K
10	HexagonsocketheadcapscrewsGB1GB_FASTENER_SCREWS_HSHCSM5X8-N.sldprt	36.25K
11	HexagonsocketheadcapscrewsGB1GB_FASTENER_SCREWS_HSHCSM6X20-N.sldprt	36.00K
12	HexagonsocketheadcapscrewsGB1GB_FASTENER_SCREWS_HSHCSM6X25-N.sldprt	35.49K
13	HexagonsocketheadcapscrewsGB1GB_FASTENER_SCREWS_HSHCSM6X40-N.sldprt	36.46K
14	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM4X20-N.sldprt	36.04K
15	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM4X25-N.sldprt	35.68K
16	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM5X10-N.sldprt	36.60K
17	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM5X20-N.sldprt	35.90K
18	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM5X25-N.sldprt	35.66K
19	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM5X8-N.sldprt	35.97K
20	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM6X20-N.sldprt	36.23K
21	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM6X25-N.sldprt	35.73K
22	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM6X35-N.sldprt	36.23K
23	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM6X40-N.sldprt	35.88K
24	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM8X25-N.sldprt	36.62K
25	HexagonsocketheadcapscrewsGBGB_FASTENER_SCREWS_HSHCSM8X30-N.sldprt	36.29K
26	Hexnutsstyle1-GradesABGBGB_FASTENER_NUT_SNAB1M4-N.sldprt	38.47K
27	Hexnutsstyle1-GradesABGBGB_FASTENER_NUT_SNAB1M6-N.sldprt	38.23K
28	HexNutStyle1GradeAB_ISOHexagonNutISO-4032-M4-W-N.sldprt	42.18K
29	HexsocketsetscrewswithflatpointGBGB_FASTENER_SCREWS_HSFPM4X5-N.sldprt	34.84K
30	InstrumentBallBearing_68_ISOISO1224-100822-R8SINC8_68.sldprt	38.32K
31	Plainwashers--ProductgradeCGBGB_FASTENER_WASHER_SMWC6.sldprt	27.77K
32	Plainwashers--ProductgradeCGBGB_FASTENER_WASHER_SMWC8.sldprt	28.32K
33	Prevailingtorqueall-metal1GBGB_HEXAGON_LOCK_TYPE1M14-N.sldprt	41.15K
34	SlottedPanHeadScrew_ISOISO1580-M4x5---5N.sldprt	34.64K
35	X轴主板.sldprt	87.36K
36	Z轴下板.sldprt	35.99K
37	Z轴顶板.sldprt	49.88K
38	丝杠X轴.sldprt	587.71K
39	丝杠Y轴.sldprt	705.63K
40	丝杠Z轴.sldprt	348.42K
41	丝杠螺母.sldprt	29.10K
42	丝杠螺母座.sldprt	50.74K
43	主轴座.sldprt	52.42K
44	主轴板.sldprt	78.06K
45	主轴电机前盖.sldprt	31.64K
46	主轴电机尾盖.sldprt	38.57K
47	主轴电机电源座.sldprt	30.96K
48	主轴电机电源接头.sldprt	30.42K
49	主轴电机身.sldprt	43.33K
50	主轴电机轴150.sldprt	28.55K
51	光轴X20.sldprt	29.68K
52	光轴Y20.sldprt	29.84K
53	光轴Z16.sldprt	29.12K
54	内侧板.sldprt	60.35K
55	内侧板右.sldprt	61.11K
56	前挡板.sldprt	48.05K
57	后内挡板.sldprt	46.18K
58	后挡板.sldprt	51.75K
59	垫块X轴螺母座.sldprt	43.50K
60	垫块Y轴螺母座.sldprt	44.16K
61	垫块Z轴螺母座.sldprt	43.67K
62	复件锤母M6^装配体底座.sldprt	36.53K
63	大侧板右.sldprt	69.37K
64	大侧板左.sldprt	77.21K
65	旋钮.sldprt	47.54K
66	电机57Back.sldprt	43.18K
67	电机57Body.sldprt	40.86K
68	电机57Head.sldprt	67.45K
69	电机座57.sldprt	54.62K
70	电机电源接头红色螺丝.sldprt	58.75K
71	电机电源接头黑色螺丝.sldprt	59.86K
72	直线轴承滑块SCS16UU.sldprt	49.16K
73	直线轴承滑块SCS20UU.sldprt	49.28K
74	装配体Motor57.sldasm	26.37K
75	装配体Motor57_1.sldasm	25.32K
76	装配体Motor57_2.sldasm	25.41K
77	装配体X轴主体.sldasm	44.38K
78	装配体X轴螺母座.sldasm	26.97K
79	装配体Y轴螺母座.sldasm	26.86K
80	装配体Z轴丝杠和螺母.sldasm	27.60K
81	装配体Z轴主体.sldasm	38.53K
82	装配体主轴电机.sldasm	30.58K
83	装配体底座.sldasm	40.98K
84	装配体电机和座及连轴器.sldasm	29.50K
85	装配体电机和座及连轴器_1.sldasm	29.99K
86	装配体连轴器635635.sldasm	24.81K
87	装配体连轴器635635_1.sldasm	25.29K
88	装配体连轴器635635_2.sldasm	24.54K
89	装配体龙门架主体.sldasm	55.22K
90	连轴器635-635.sldprt	84.14K
91	锤母M5.sldprt	35.70K
92	锤母M6.sldprt	37.00K
93	龙门架后板.sldprt	52.17K
94	龙门架底板.sldprt	64.16K
95	龙门架支撑座.sldprt	42.71K
