3D打印机（ID:251066）

机械设备 / 3D打印机 / 3D打印机

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	3D_Printer_step.prt	434.00K
2	ACM2004A1_FGBW.prt	1.17M
3	Aluminum_Bar_Head.prt	127.50K
4	Arm_Holder_BedHeat.prt	352.00K
5	Arm_Holder_BedHeat_Mirror.prt	352.00K
6	Beam_Stopper_Switcher.prt	156.00K
7	Bed_Heat.prt	445.00K
8	Belt_Vertical.prt	97.00K
9	Belt_X.prt	97.00K
10	Belt_Y.prt	96.50K
11	Bottom_Printer.prt	213.00K
12	Brushless_DC_Fan.prt	388.50K
13	Closed Linear Bearing-LBCA-6-S.prt	772.00K
14	Flanged_Ball_Bearing_4.90.prt	93.50K
15	Front_plate.prt	1.30M
16	Front_plate_Rear.prt	413.50K
17	Head_Extruder.prt	267.00K
18	Heater_Default_As Machined_.prt	227.50K
19	Heat_Sink.prt	442.00K
20	hex nut style 2 gradeab_iso_Hexagon Nut ISO - 4033 - M5 - W - S.prt	178.50K
21	hex thin nut chamfered gradeab_iso_Hexagon Thin Nut ISO - 4035 - M6 - N.prt	124.00K
22	hex thin nut gradeb_iso_Hexagon Nut ISO - 4036 - M3 - N.prt	103.50K
23	hex thin nut gradeb_iso_Hexagon Nut ISO - 4036 - M5 - N.prt	102.50K
24	Hob_8mm.prt	104.00K
25	Hob_Screw_Motor.prt	271.00K
26	Holder_Shaft_Extruder.prt	455.00K
27	Holder_Shaft_Extruder_Mirror.prt	520.00K
28	Holder_Spools.prt	180.50K
29	Knob.prt	315.50K
30	Leg.prt	79.00K
31	Mech_Endstop.prt	540.00K
32	Mother_card_STEP.prt	7.21M
33	Part2^3D_Printer.prt	112.00K
34	plain washer 10669 type nl_iso_ISO 10669-3-N.prt	89.00K
35	plain washer 10673 type snl_iso_ISO 10673-3.6-S.prt	89.00K
36	Plastic_Enclosure.prt	140.00K
37	Plastic_Head_exdruder.prt	214.00K
38	Plastic_Head_exdruder_Front.prt	184.00K
39	Plug_Screen.prt	1.04M
40	Plug_Stepper_Motor.prt	171.50K
41	prevailing torque hex nut_am_AM-M3-S.prt	177.00K
42	Push_Filement_Extruder.prt	92.00K
43	richco_hurc-4-01-clip_4-01 - 6.4mm Dia.prt	118.50K
44	Rubber_AntiVibration_Legs.prt	108.50K
45	Screw_Head_Extruder.prt	103.50K
46	Screw_Shaft.prt	2.23M
47	SD_Card.prt	439.00K
48	Serrated_Pulley_extruder.prt	640.00K
49	Shaft_5mm_450.prt	92.00K
50	Shaft_8mm_280.prt	92.00K
51	Shaft_8mm_400.prt	92.00K
52	Shaft_Horizontal_Displacement.prt	84.00K
53	Shaft_Vertical.prt	92.00K
54	Side_plate.prt	604.00K
55	Side_plate_Left.prt	489.50K
56	socket countersunk head screw_am_B18.3.5M - 3 x 0.5 x 10 Socket FCHS -- 10S.prt	253.50K
57	socket countersunk head screw_am_B18.3.5M - 3 x 0.5 x 30 Socket FCHS -- 30S.prt	616.00K
58	socket countersunk head screw_iso_ISO 10642 - M3 x 16 --- 16S.prt	348.00K
59	socket head cap screw_am_B18.3.1M - 3 x 0.5 x 50 Hex SHCS -- 18SHX.prt	423.50K
60	socket head cap screw_iso_ISO 4762 M3 x 10 --- 10N.prt	117.00K
61	socket head cap screw_iso_ISO 4762 M3 x 10 --- 10S.prt	280.50K
62	socket head cap screw_iso_ISO 4762 M3 x 12 --- 12S.prt	307.50K
63	socket head cap screw_iso_ISO 4762 M3 x 16 --- 16S.prt	377.50K
64	socket head cap screw_iso_ISO 4762 M3 x 20 --- 20S.prt	453.00K
65	socket head cap screw_iso_ISO 4762 M3 x 25 --- 18S.prt	438.00K
66	socket head cap screw_iso_ISO 4762 M3 x 6 --- 6S.prt	204.00K
67	socket head cap screw_iso_ISO 4762 M4 x 16 --- 16S.prt	308.50K
68	socket head cap screw_iso_ISO 4762 M5 x 30 --- 22S.prt	369.00K
69	socket set screw flat point_iso_ISO 4026 - M2 x 3-S.prt	164.50K
70	Spool.prt	1.55M
71	Spring.prt	298.50K
72	Standoffs_10.prt	89.00K
73	Standoffs_3.6X6.5x15.5.prt	88.50K
74	Standoffs_L15.prt	88.50K
75	Standoffs_L24.prt	88.50K
76	Standoffs_motherCard.prt	111.50K
77	Stepper_ScrewShaft.prt	79.50K
78	Stepping_Motor_17HD4001-20N.prt	1.33M
79	Stepping_Motor_17HD4063-01N.prt	1.34M
80	Support_bed.prt	676.00K
81	Support_Extruder.prt	294.50K
82	Support_HeadExtruder.prt	126.50K
83	Timing_Pulley_10.prt	313.00K
84	Timing_Pulley_10_Horizontal.prt	292.00K
85	Top_Plate.prt	290.50K
86	Top_Plate_Down.prt	306.50K
87	Tunnel_Filament.prt	98.50K
88	T_Nut.prt	98.50K
