吉利ce正向 -06_顶盖总成_ROOF ASSY（ID:2655320）

机械设备 / 非标机械 / 吉利ce正向 -06_顶盖总成_ROOF ASSY

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	17585456885842.zip	86.29M
2	01217853WP_ROOF_FRT_RAIL_ASSY.CATPart	53.65K
3	01217853_ROOF_FRT_RAIL_ASSY.CATProduct	34.35K
4	01217854_PNL_FRT_HEADER.CATPart	15.44M
5	01217855_BRKT_MTG_ROOF_LAMP.CATPart	25.41M
6	01217856_PNL_ROOF_REINF_NO.1_ASSY.CATProduct	32.60K
7	01217857_PNL_ROOF_REINF_NO.1.CATPart	14.63M
8	01218335_ROOF_ASSY.CATProduct	37.59K
9	01218336_ROOF_OUTER_PLATE.CATPart	8.92M
10	01218337_PNL_ROOF_REINF_NO.2.CATPart	12.32M
11	01218338_PNL_ROOF_REINF_NO.3.CATPart	9.03M
12	01218339_PNL_RR_HEADER.CATPart	8.75M
13	01220868_REINF_A2_SUNROOF_RING.CATProduct	19.27K
14	01220869_REINF_SUNROOF_RING.CATPart	27.22M
15	01220920WP_ROOF_FRT_RAIL_ASSY.CATPart	47.15K
16	01220920_ROOF_FRT_RAIL_ASSY.CATProduct	33.52K
17	01220924_PNL_FRT_HEADER_ASSY.CATProduct	25.86K
