#55 防撞屏障组件 _ Fusion 360 _ 榛子图形（ID:2722172）

机械设备 / 非标机械 / #55 防撞屏障组件 _ Fusion 360 _ 榛子图形

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	01impactbarriers.pdf	489.58K
2	02asbbollard.pdf	190.27K
3	03asbanglebrackets.pdf	136.03K
4	04bollard.pdf	101.39K
5	05cap.pdf	104.89K
6	06anglebrackets.pdf	100.48K
7	07base.pdf	100.53K
8	08impactsupport.pdf	98.63K
9	08impactsupportflat.pdf	97.24K
10	09pedestriansupport.pdf	98.27K
11	09pedestriansupportflat.pdf	104.35K
12	10impacttube.pdf	96.30K
13	11pedestriantube.pdf	96.23K
14	17604478043058.zip	67.75M
15	91578A108_SteelStudAnchor.step	625.31K
16	91578A108_SteelStudAnchor.stl	9.18M
17	95105A191_Zinc-PlatedSteelHeavy-DutyRivetNut.step	785.70K
18	95105A191_Zinc-PlatedSteelHeavy-DutyRivetNut.stl	3.56M
19	96144A211_Fine-ThreadAlloySteelSocketHeadScrew.step	500.30K
20	96144A211_Fine-ThreadAlloySteelSocketHeadScrew.stl	2.81M
21	anglebrackets.step	17.29K
22	anglebrackets.stl	36.41K
23	base.step	10.25K
24	base.stl	56.72K
25	bollard.step	33.22K
26	bollard.stl	461.31K
27	cap.step	10.44K
28	cap.stl	444.71K
29	ImpactBarriersv30.f3d	2.03M
