麦克纳姆轮万向轮驱动模块（左）（ID:29944）

设备部件 / 操作件 / 麦克纳姆轮万向轮驱动模块（左）

©非原创

160

平面图

3D视图

文件列表

#	文件名称	文件大小
1	1-4in shaft 5in long 6061K413.SLDPRT	201.00K
2	10-32 flat head machine screw 1in long 91771A833.SLDPRT	526.50K
3	10-32 Tee-nut 90975A021.SLDPRT	1.19M
4	10-32 threaded stud 1in long.SLDPRT	99.50K
5	10-32x0500_shcs.sldprt	679.00K
6	10-32x2000_shcs.sldprt	636.00K
7	10-32_nylock_nut.sldprt	138.50K
8	12-2_522C.sldprt	275.00K
9	12010-0_rod_guide.sldprt	429.50K
10	120_75-PCY(2x,D-241)(F,D-231-1)0000_0_dummy.sldprt	72.50K
11	120_75-PY(2x,D-241)(F,D-231-1).sldasm	921.50K
12	125 rivet.sldprt	119.00K
13	12P0Y010_rear_head.sldprt	553.00K
14	14T CIM Gear.sldprt	83.00K
15	1in drywall screw.SLDPRT	431.50K
16	25chain_inside_link.SLDPRT	129.00K
17	25chain_outside_link.SLDPRT	130.00K
18	25chain_pin.SLDPRT	88.50K
19	25chain_roller.SLDPRT	109.50K
20	2mm x 2mm x 10mm Machine Key_smart.sldprt	68.50K
21	4-40 fhms 91771A115.SLDPRT	543.00K
22	4HD Mecanum Hub.sldprt	451.50K
23	4HD Mecanum Left Plate_DefaultSM-FLAT-PATTERN.sldprt	234.00K
24	4HD Mecanum Roller Core.sldprt	155.00K
25	4HD Mecanum roller skin.sldprt	188.00K
26	4HD Mecanum roller.sldasm	164.50K
27	4in_plaction_tread.SLDPRT	118.50K
28	4MW_d01.sldprt	1016.50K
29	4PlactionWheel-asm.SLDASM	1.01M
30	5-16 washer_smart.sldprt	60.50K
31	50T 20dp 375hex_Inch - Spur gear 20DP 50T 14.5PA .372FW ---S50N3.0H2.0L0.25N.sldprt	136.50K
32	8mm keyed shaft 1439K211.SLDPRT	294.00K
33	8mm shaft collar 9506T400.SLDPRT	852.00K
34	8mm_spring_clip am-0033.sldprt	79.50K
35	98023A029 Washer.SLDPRT	106.50K
36	am-0096a.SLDPRT	147.50K
37	am-0096a_cut-down.SLDPRT	133.50K
38	am-0588.SLDPRT	122.50K
39	am-1165 or mcmaster 93882A217.SLDPRT	382.00K
40	am-2448_modified.SLDPRT	148.00K
41	am-3026L 4HD Mecanum Left.SLDASM	652.00K
42	AMT103-V.SLDPRT	3.88M
43	Brass tube.sldprt	110.00K
44	C-120_75-PY0_rod.sldprt	296.50K
45	CIM motor-1.sldprt	75.00K
46	cim_bearing_bracket.SLDPRT	340.50K
47	CIM_with_gears.SLDASM	534.50K
48	clamp_threaded_half_6436K120.SLDPRT	691.50K
49	concept 2 fixed module.SLDASM	2.08M
50	concept2 stiffener asy.SLDASM	759.50K
51	D-14053.sldprt	363.50K
52	D-154.sldprt	250.50K
53	D-231-1-dummy.sldprt	104.00K
54	D-3556.sldprt	248.00K
55	D-4462.sldprt	164.00K
56	D-5867.sldprt	137.00K
57	D-8383.sldprt	188.00K
58	F608-ZZ flanged 8mm bearing from Inventables.SLDPRT	181.00K
59	first_gear_reduction_pair.SLDASM	414.50K
60	flanged bearing 8mm ID 7804K145.SLDPRT	461.00K
61	FR6ZZ Bearing-ab.sldprt	62.00K
62	FR6_smart.sldprt	62.00K
63	FR8ZZ Hex Bearing.sldprt	68.50K
64	Loop of No 25 Chain1.SLDASM	282.00K
65	Loop of No 25 Chain2.SLDASM	266.00K
66	Lowes_23966_0.5in_schedule40_pcv_cut_1.053in_long.SLDPRT	183.00K
67	mechanum 4in left.SLDASM	878.00K
68	No 25 Chain Module.SLDASM	1.06M
69	No25 Sprocket 10-tooth am-0505.SLDPRT	562.00K
70	No25 Sprocket 16-tooth am-0749.SLDPRT	605.50K
71	No25 Sprocket 22-tooth am-0646.SLDPRT	666.00K
72	No25 Sprocket 34-tooth am-0509.SLDPRT	776.50K
73	No25 Sprocket 42-tooth am-0235.SLDPRT	903.50K
74	Oval Semi-Tubular Rivet.sldprt	133.50K
75	Phoenix Octocanum Left Module.SLDASM	4.50M
76	Phoenix Octocanum Left Module.STEP	19.97M
77	R6ZZ Bearing_smart.sldprt	61.50K
78	sliding spacer made from 8627K539.SLDPRT	127.00K
79	Spacer am-1151.sldprt	60.50K
