龙门式打印机（ID:3123661）
查找相似图纸
查找相似图纸
截图
AI截图渲染
✨AI图片渲染
0.png)
1.png)
2.png)
3.png)
4.png)
| # | 文件名称 | 文件大小 |
|---|---|---|
| 1 | BF12_FLOATED.ipt | 188.50K |
| 2 | BK12_END.ipt | 216.50K |
| 3 | BRACKET1X2.ipt | 132.50K |
| 4 | BRACKET2X1_V3.ipt | 153.00K |
| 5 | BRACKET2_ASSEM_ASM.iam | 113.50K |
| 6 | BRACKET_ASSEM_ASM.iam | 119.00K |
| 7 | COUPLING.ipt | 106.50K |
| 8 | ENDCAP_120_30.ipt | 122.50K |
| 9 | ENDCAP_6060_ROUND.ipt | 115.50K |
| 10 | ENDCAP_6060_ROUND_CORNER.ipt | 114.00K |
| 11 | ENDCAP_6060_V2.ipt | 115.00K |
| 12 | FRAME2C_ASM.iam | 503.00K |
| 13 | FRAME2_ASM.iam | 476.00K |
| 14 | FRAME_LOCK_NUT_M3.ipt | 97.00K |
| 15 | FRAME_LOCK_NUT_V3.ipt | 97.00K |
| 16 | HFS6_30120_570.ipt | 241.00K |
| 17 | HFS6_30120_60.ipt | 258.00K |
| 18 | HFS6_30120_880.ipt | 250.50K |
| 19 | HFS6_30120_Z_PLATE.ipt | 256.00K |
| 20 | HFS6_30120_Z_PLATE_BRACE.ipt | 262.00K |
| 21 | HFS6_3030_385.ipt | 140.50K |
| 22 | HFS6_6060_100.ipt | 261.50K |
| 23 | HFS6_6060_1370.ipt | 223.00K |
| 24 | HFS6_6060_750.ipt | 232.50K |
| 25 | LONGSCREW_ASSEM_ASM.iam | 153.50K |
| 26 | M3_SCREW.ipt | 107.50K |
| 27 | M3_SCREW_ASSEM_ASM.iam | 98.50K |
| 28 | M3_WASHER.ipt | 94.00K |
| 29 | M5_10_SCREW.ipt | 107.00K |
| 30 | M5_16_SCREW.ipt | 107.00K |
| 31 | M5_36_SCREW.ipt | 101.00K |
| 32 | M5_40_SCREW.ipt | 100.00K |
| 33 | M5_8_12_SCREW.ipt | 109.50K |
| 34 | M5_SCREW_ASSEM_ASM.iam | 99.00K |
| 35 | MEDIUM_SCREW_ASSEM_ASM.iam | 209.50K |
| 36 | MOTORASSEM_ASM.iam | 107.50K |
| 37 | QSH6018-65-28-210_.ipt | 127.50K |
| 38 | RM1605.ipt | 131.50K |
| 39 | ROUTER_HOLDER.ipt | 261.50K |
| 40 | ROUTER_HOLDING_FIXTURE_ASM.iam | 229.00K |
| 41 | SBR16S_LONG_RAIL.ipt | 106.50K |
| 42 | SBR16S_MEDIUM_RAIL.ipt | 105.00K |
| 43 | SBR16S_SHORT_RAIL.ipt | 112.50K |
| 44 | SBR16UU.ipt | 109.00K |
| 45 | SCREW_LONG_.ipt | 84.50K |
| 46 | SCREW_MEDIUM.ipt | 85.50K |
| 47 | SCREW_SHORT.ipt | 91.00K |
| 48 | SMALL_SCREW_ASSEMBLY_ASM.iam | 178.00K |
| 49 | TRAVEL_CONNECTOR.ipt | 153.50K |
| 50 | TRAVEL_CONNECTOR_MEDIUM.ipt | 155.00K |
| 51 | X_INSERT_ASM.iam | 101.00K |
| 52 | X_INSERT_CONNECTOR.ipt | 87.50K |
| 53 | X_MOTOR_MNT.ipt | 157.50K |
| 54 | X_STABILIZER_INSERT.ipt | 108.00K |
| 55 | Y_BEARING_ASM.iam | 157.00K |
| 56 | Y_BEARING_V2.ipt | 169.50K |
| 57 | Y_MOTOR_MNT.ipt | 157.00K |
| 58 | Z_AXIS_ASSEM_ASM.iam | 512.50K |
| 59 | Z_BEARING_GOOD.ipt | 203.50K |
| 60 | Z_MOTOR_MNT_GOOD.ipt | 152.50K |
| 61 | 龙门式打印机.stp | 4.29M |
| 62 | 龙门式打印机.stp.iam | 691.50K |
此图纸下载需要30金币
立即下载
发布者
忧虑的麦片
创作: 16485
粉丝: 4
加入时间：2025-08-30
模型信息
图纸ID：3123661
图纸格式：ipt,iam,stp
文件大小：8.68M
所需金币：30
上传时间：2026-04-01 19:47:33
是否可编辑：可修改，不包括参数
软件版本：Inventor 2023
