树莓派4zero2开发板主板（ID:338991）

数码电器 / 电脑相关 / 树莓派4zero2开发板主板

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	16636819704296.zip	25.25M
2	54548-2271, 22 Pin FPC Connector, Raspberry Pi Zero 2 W.SLDPRT	1.08M
3	Crystal Resonator, Raspberry Pi Zero 2 W.SLDPRT	101.58K
4	Diode, Schottky, Raspberry Pi Zero 2 W.SLDPRT	68.95K
5	LED, Raspberry Pi Zero 2 W.SLDPRT	64.15K
6	MicroUSB Port, Raspberry Pi Zero 2 W.SLDPRT	1.18M
7	Mini HDMI Receptacle Port, Raspberry Pi Zero 2 W.SLDPRT	662.48K
8	PAM2306AYPKE, Switching Voltage Regulators Dual PWM Step-Down 40uA 1A 1.5MHz, Raspberry Pi Zero 2 W.SLDPRT	378.64K
9	PCB, Raspberry Pi Zero 2 W.SLDPRT	385.60K
10	Raspberry Pi Zero 2 W.SLDASM	1.64M
11	Raspberry Pi Zero 2 W.STEP	12.63M
12	Raspberry Pi Zero 2 W.x_b	4.69M
13	RP3A0-AU 2105 201221C, Raspberry Pi Zero 2 W.SLDPRT	50.31K
14	RT8088AWSC, IC Reg Buck Prog 3A Sync 15WLCSP, Raspberry Pi Zero 2 W.SLDPRT	119.76K
15	RT9081A-1BGQZA, Fixed LDO Voltage Regulator, 0.8V-5.5Vin, 140mV drop, 1.25Vout, 0.5Aout, Raspberry Pi Zero 2 W.SLDPRT	119.59K
16	SD Card Slot, Raspberry Pi Zero 2 W.SLDPRT	445.06K
17	SMD Capacitor, Configurable, Raspberry Pi Zero 2 W.SLDPRT	736.96K
18	SMD Inductor, Configurable, Raspberry Pi Zero 2 W.SLDPRT	120.05K
19	SMD Resistor, Configurable, Raspberry Pi Zero 2 W.SLDPRT	707.93K
20	Wireless Module Cover, Raspberry Pi Zero 2 W.SLDPRT	162.58K
