Buell XB12 发动机总成详图（ID:420905）

交通运输 / 车辆相关 / Buell XB12 发动机总成详图

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	16715488261036.zip	96.22M
2	1.jpg	169.31K
3	2009BuellXB12EngineTopEnd.x_t	75.86M
4	Rodation1.gif	3.44M
5	Rotation2.gif	3.83M
6	2009BuellXB12EngineTopEnd.SLDASM	30.66M
7	95185A205_ZINC-PLATEDSTEELPRESS-FITNUTFORSHEETMETAL.SLDPRT	103.59K
8	BoltHexHeadHD-3987.SLDPRT	62.38K
9	CollarValveSpring18258-02.SLDPRT	24.07K
10	Cylinder16956-02A22710-09.SLDPRT	2.95M
11	CylinderBaseGasketJamesGasketJGI-16774-96.SLDPRT	95.51K
12	CylinderHeadBoltLongShort16478-85A16480-92ALongBolt16478-85A.SLDPRT	63.84K
13	CylinderHeadBoltLongShort16478-85A16480-92AShortBolt16480-92A.SLDPRT	63.38K
14	CylinderHeadFrontAssembly16872-09.SLDASM	25.40K
15	CylinderHeadFrontRear16874-0716877-0716872-0916875-09FrontCylinderHead.SLDPRT	5.57M
16	CylinderHeadFrontRear16874-0716877-0716872-0916875-09RearCylinderHead.SLDPRT	5.66M
17	CylinderHeadFrontWithValvesAssembly.SLDASM	31.68K
18	CylinderHeadGasket1200ccJamesGasketsJGI-16773-85-T.SLDPRT	34.65K
19	CylinderHeadLocatingO-RingOilDrainSealJamesGasketsJGI-26432-76-A.SLDPRT	23.39K
20	CylinderHeadPigTainfrom8313K22_BRASSRODBentafterinstallation.SLDPRT	104.64K
21	CylinderHeadRearAssembly16875-09.SLDASM	24.15K
22	CylinderHeadRearWithValvesAssembly.SLDASM	30.84K
23	CylinderOilTubeDrainV-Twin16-0911Bent.SLDPRT	97.41K
24	CylinderStud16832-86C.SLDPRT	122.35K
25	CylinderwithDowelsandPigtailFront.SLDASM	23.00K
26	CylinderwithDowelsandPigtailRear.SLDASM	23.62K
27	DowelLocatingPinCylinderHeadAndTrapdoor16573-83A.SLDPRT	28.74K
28	DowelPinHD215.SLDPRT	22.02K
29	EngineMountCenterTieBarL0160.02A8A.SLDPRT	31.76K
30	EngineTemperatureSensorWirePotectionY0386.5AA.SLDPRT	306.49K
31	EnginetoCylinderBaseInterface.SLDPRT	121.30K
32	EnginetoCylinderBaseInterfaceWithStuds.SLDASM	24.79K
33	ExhaustFlangeRetainingClip65325-83A.SLDPRT	22.98K
34	ExhaustHeaderFlange1861-0889.SLDPRT	26.72K
35	ExhaustPortGasketJamesGasketsJGI-65324-83-A.SLDPRT	23.63K
36	ExhaustStud16715-83.SLDPRT	105.06K
37	ExhaustValve18691-02.SLDPRT	27.97K
38	ExhaustValveSeat18011-86.SLDPRT	23.53K
39	FlatWasherHD-6787BA0613.2Z.SLDPRT	22.47K
40	FrontIsolatorBoltCA0013.02A8.SLDPRT	179.08K
41	FrontIsolatorKitL1501.02A8.SLDASM	21.77K
42	FrontIsolatorL0501.4A8.SLDPRT	481.90K
43	FuellineP0464.02A8A.SLDPRT	79.45K
44	GasketRockerCoverScrewJamesGasketsJGI-63858-49.SLDPRT	22.71K
45	HeaderNutDA0500.12FZ.SLDPRT	39.56K
46	HeadMountandPinchBoltAA0712.2CZB.SLDPRT	47.11K
47	HeadTemperatureSensorP0278.4A8A.SLDPRT	187.46K
48	HeadTemperatureSensorwithSensorWireProtectionAssemblyP0278.4A8A.SLDASM	21.96K
49	IgnitionCoilY0300.02A8.SLDPRT	207.93K
50	IgnitionStrapCoilBracket16357-02A.SLDPRT.SLDASM	22.90K
51	IgnitionStrapCoilBracket16357-02ASheetMetalPart.SLDPRT	62.55K
52	IntakeFlange27327-07A.SLDPRT	30.61K
53	IntakeSealJamesGasketsJGI-26995-86-A.SLDPRT	22.63K
54	IntakeValve18690-02.SLDPRT	27.14K
55	IntakeValveSeat18020-07.SLDPRT	22.63K
56	KeeperValveCollar18260-02.SLDPRT	31.38K
57	PCVValve17607-00Y.SLDPRT	198.74K
58	PCVValveGrommet17606-00YA.SLDPRT	24.77K
59	PushrodCoverBaseGasketFrontRear17608-00Y17649-02Front.SLDPRT	252.41K
60	PushrodCoverBaseGasketFrontRear17608-00Y17649-02Rear.SLDPRT	254.21K
61	PushrodCoverFrontRear17986-00Y17979-0217979-00YFrontCover.SLDPRT	494.70K
62	PushrodCoverFrontRear17986-00Y17979-0217979-00YRearCover.SLDPRT	510.15K
63	PushrodCoverScrewHD4847.SLDPRT	181.03K
64	PushrodIntakeExhaust17909-0217908-02ExhaustPushrod.SLDPRT	27.67K
65	PushrodIntakeExhaust17909-0217908-02IntakePushrod.SLDPRT	27.76K
66	RockerArmBearing17429-91AsPressedandReamed.SLDPRT	26.68K
67	RockerArmFrontIntake-RearExhaust17360-83BWithBushingsAssembly-1.SLDASM	22.77K
68	RockerArmFrontIntake-RearExhaust17360-83BWithBushingsAssembly.SLDASM	22.92K
69	RockerArmFrontIntake-RearExhaustRearIntake-FrontExhaust17360-83B17375-83BFrontIntake-RearExhaust17360-83B.SLDPRT	265.49K
70	RockerArmFrontIntake-RearExhaustRearIntake-FrontExhaust17360-83B17375-83BRearIntake-FrontExhaust17375-83B.SLDPRT	264.79K
71	RockerArmRearIntake-FrontExhaust17375-83BWithBushingsAssembly-1.SLDASM	23.46K
72	RockerArmRearIntake-FrontExhaust17375-83BWithBushingsAssembly.SLDASM	23.14K
73	RockerArmShaft17611-83A.SLDPRT	24.58K
74	RockerBoxBoltWithWasherHD3849.SLDPRT	74.95K
75	RockerBoxCoverFrontRear17604-00YB17605-00YB17642-02A17684-0917668-09Front.SLDPRT	762.22K
76	RockerBoxCoverFrontRear17604-00YB17605-00YB17642-02A17684-0917668-09Rear.SLDPRT	752.59K
77	RockerBoxCoverScrewHD2486.SLDPRT	52.39K
78	RockerBoxCoverToCylinderHeadGasketJamesGasketJGI-16779-99-X.SLDPRT	314.25K
79	RockerBoxRockerArmFastenerHD4718A.SLDPRT	65.28K
80	RockerBoxScrewHexFangeHeadHD1039.SLDPRT	117.07K
81	RockerCoverGasketInnerJamesGasketsJGI-17695-07.SLDPRT	111.40K
82	RockerCoverGasketOuterJamesGasketsJGI-17362-07.SLDPRT	291.19K
83	RockerCoverInnerLower17598-07A17579-07ADefault.SLDPRT	1.38M
84	RockerCoverInnerLowerwithRockerArmsAssemblyDefault-_flexible1.SLDASM	24.86K
85	RockerCoverInnerLowerwithRockerArmsAssemblyDefault-_flexible2.SLDASM	25.75K
86	SCREWSEMHEXSOCKETHEADCAP3480A.SLDPRT	71.47K
87	ScrewSHCSGR838-16x1.875AA0615.2CZB.SLDPRT	60.60K
88	ScrewSockerHeadCapHD-4748.SLDPRT	50.29K
89	SparkPlugNGKDCPR8EIX.SLDPRT	153.65K
90	SparkPlugWireY0204.02A8CFrontCylinder.SLDPRT	95.68K
91	SparkPlugWireY0204.02A8CRearCylinder.SLDPRT	97.11K
92	ThrottleBodyManifold49mmP0803.5AA.SLDPRT	12.02M
93	UpperPushRodCoverO-ring11190.SLDPRT	22.46K
94	ValveGuide16461-02.SLDPRT	23.36K
95	ValveSpring18245-02ValveClosed.SLDPRT	257.79K
