平整CF法兰套装（ID:82964）

设备部件 / 管道附件 / 平整CF法兰套装

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	CF-1.33-BLANK-FLANGE.IGS	221.74K
2	CF-1.33-BLANK-FLANGE.SLDPRT	110.46K
3	CF-1.33-COPPER-GASKET.IGS	64.94K
4	CF-1.33-COPPER-GASKET.SLDPRT	70.42K
5	CF-1.33-STOCK-FLANGE (0.750OD-0.620ID-0.065W) 4K.JPG	2.10M
6	CF-1.33-STOCK-FLANGE (0.750OD-0.620ID-0.065W) DIMENSIONS.PDF	42.23K
7	CF-1.33-STOCK-FLANGE (0.750OD-0.620ID-0.065W).IGS	264.02K
8	CF-1.33-STOCK-FLANGE (0.750OD-0.620ID-0.065W).SLDDRW	163.20K
9	CF-1.33-STOCK-FLANGE (0.750OD-0.620ID-0.065W).SLDPRT	128.59K
10	CF-2.75-BLANK-FLANGE.IGS	203.64K
11	CF-2.75-BLANK-FLANGE.SLDPRT	79.16K
12	CF-2.75-COPPER-GASKET.IGS	78.72K
13	CF-2.75-COPPER-GASKET.SLDPRT	62.03K
14	CF-2.75-STOCK-FLANGE (1.900OD-1.500ID-0.200W).IGS	259.93K
15	CF-2.75-STOCK-FLANGE (1.900OD-1.500ID-0.200W).PDF	72.48K
16	CF-2.75-STOCK-FLANGE (1.900OD-1.500ID-0.200W).SLDDRW	165.78K
17	CF-2.75-STOCK-FLANGE (1.900OD-1.500ID-0.200W).SLDPRT	78.09K
18	CF-4.50-BLANK-FLANGE.IGS	248.80K
19	CF-4.50-BLANK-FLANGE.SLDPRT	81.51K
20	CF-4.50-COPPER-GASKET.IGS	78.72K
21	CF-4.50-COPPER-GASKET.SLDPRT	60.13K
22	CF-4.50-STOCK-FLANGE (2.875OD-2.469ID-0.203W).IGS	305.42K
23	CF-4.50-STOCK-FLANGE (2.875OD-2.469ID-0.203W).PDF	73.65K
24	CF-4.50-STOCK-FLANGE (2.875OD-2.469ID-0.203W).SLDDRW	159.27K
25	CF-4.50-STOCK-FLANGE (2.875OD-2.469ID-0.203W).SLDPRT	100.21K
26	gasket.JPG	448.87K
27	Knife-Edge-4K.JPG	1.70M
